Riso Digital Duplicator SF 9350: An upgraded print system for use in various settings

Category:

SF9350EII



High-speed 150 ppm printing

Achieving 1000 pages printed in approx. 7 minutes, this surprisingly rapid rate will efficiently support your heavy paperwork requirements.

Quick Master Making mode

A new function, Quick Master Making mode, shortens the master-making time while still maintaining high image quality.

Heavy-load paper feeding

The paper feed tray has a capacity of 1000 sheets* for both feeding and receiving, which ensures uninterrupted printing over a longer period.

*When using the following weights of paper: 64 gsm to 80 gsm.

Overwhelmingly economical print costs

The SF EⅡ series makes prints from a master. The more pages generated from each master the lower the cost per print. This means you can benefit from highly economical large-volume printing in the long run.

Multiple Page Printing

Page layout printing combines multiple copies of the same page, or copies of multiple pages onto a single printed page to save paper. Conveniently condense bulky multiple-page documents in an easy-to-read format. These functions are available when using the printer driver.

Versatile paper handling capability

The SF EⅡ series plays multiple roles, accepting a wide range of paper types such as recycled paper, coarse paper, cards and envelopes.

Riso SF9350 EⅡ

Master Making/Printing Methods High-speed digital master-making/Fully automatic printing
Original Type Book or sheet
Master Making Time*1 Quick Master
Making mode		 – Approx. 14 seconds (A4, long-edge feed)
– Approx. 18 seconds (A4, short-edge feed)
Normal master
making mode		 – Approx. 16 seconds (A4, long-edge feed)
– Approx. 20 seconds (A4, short-edge feed)
Resolution Scanning 600 dpi × 600 dpi
Printing 600 dpi × 600 dpi, Quick Master Making mode: 600 dpi × 400 dpi
Maximum Scanning Area 297 mm × 432 mm
Print Paper Weight 46 gsm to 210 gsm
Print Paper Size*2 100 mm × 148 mm to 310 mm × 432 mm
Maximum Printing Area 291 mm × 413 mm
Paper Feed Tray Stacking Capacity 1000 sheets*3, stacking height of 110 mm or lower
Paper Receiving Tray Stacking Capacity 1000 sheets*3, stacking height of 110 mm or lower
Print Speed 6 levels: 60, 80, 100, 120, 130, and 150 (High Speed *4) ppm
Print Position Adjustment Horizontal: ±15 mm, Vertical: ±10 mm
Image Processing Mode Line, Photo (Standard/Portrait), Duo (Standard/Line/Photo/Shadow off), Pencil
(Darker/Lighter)
Print Reproduction Ratio Zoom (50% to 200%), Free, 100% reduction ratio, Margin+ (90% to 99 %), 4 levels of enlargement (163%, 141%, 122%, 116%), 4 levels of reduction (87%, 82%, 71%, 61%)
User Interface Color touch panel
Functions Image, Contrast, Size, Paper Size Detection, D-Feed Check, Dot Process, Contrast Adj., Tone Curve, Multi-up Print, Book Shadow, Top Margin Adj., Binding Margin Adj., Max. Scan, Ink Saving, Quick Master Making, Preview, ADF-Semi-Auto*5, Storage, Overlay, Print Speed Adj., Print Density Adj., Print Position Adj., Interval, Renew Page, Auto Page Renewal, Rotate, Special Paper Ctrl, Program, Slip sheet sorting, Job Separation*6, Job Memory, Reservation, Editor, Idling Action, Confidential, My Direct Access, Meter Display, ID Counter Report, Proof Copy, Direct Printing, USB Job List, Paper Memory Prnt, Scanning mode, Admin., Auto Sleep, Auto Power-OFF, Power-OFF Schedule, ECO mode, Protect, RISO iQuality System
PC Interface USB2.0, Ethernet:100BASE-TX, 10BASE-T
Ink Supply Full automatic (1000 ml/cartridge)
Master Supply/Disposal Full automatic(A3: approx. 220 sheets per roll)/Disposal capacity: approx. 100 sheets
Power Source AC 100-240 V, 50-60 Hz <3.4-1.6 A>
Power Consumption Standard Max.: 300 W, Ready: 20 W or lower, Sleep: 5 W or lower, Power-OFF: 0.5 W or lower
Optional Accessories
Connected*7		 Max.: 315 W, Ready: 30 W or lower, Sleep: 10 W or lower, Power-OFF: 0.5 W or lower
Dimensions (W×D×H) In use 1415 mm × 670 mm*8 × 1065 mm*9
In storage 780 mm × 670 mm*8 × 1065 mm*9
Required Space (W×D×H) 1415 mm × 1240 mm × 1515 mm*9
Weight 102 kg*10
  • *1 Measurement value when set to 100% reproduction ratio.
  • *2 When the optional Wide Stacking Tray is installed, you can use paper up to a size of 310 mm × 555 mm by setting [Custom Paper Entry].
    Depending on the paper type and paper size, papers may not be aligned properly.
  • *3 When using the following weight of paper; 64 gsm to 80 gsm
  • *4 If the temperature of the inside of the print drum (cylinder) is less than 5°C, [High Speed] is not usable.
  • *5 Usable when the optional auto document feeder is installed.
  • *6 Usable when the optional Job Separator is installed.
  • *7 When all the following optional accessories are installed, Auto Document Feeder, Job Separator, IC Card Reader.
  • *8 The depth does not include the stabilizers for the dedicated stand.
  • *9 The height includes the dedicated stand.
  • *10 The weight does not include the ink, master roll, and stand.
  • Notes: The specifications are subject to change without prior notice.
